I. Technical Visualization
II. Regenerative Energy Loop
The H Nebula utilizes a closed-loop "Water-to-Thrust" system, eliminating the need for traditional fuel logistics and heavy battery arrays.
III. Core Patent Claims
Claim 4 Structural Propulsion: Hubless rim-driven fans with 24-slot stators integrated directly into 7075-T6 isogrid airframe ducts.
Claim 2 Prone Transition: 90-degree mechanized pilot rotation to achieve minimal frontal area and maximum aerodynamic efficiency.
Claim 3 HHO Life Support: On-board medical-grade O2 scrubbing from electrolysis byproducts.
Claim 5 Gyroscopic Battery: Central kinetic energy storage providing 50k+ RPM inertial stability.
IV. Precision Manufacturing
- Tolerances: +/- 0.0002" via 3-Axis CNC Milling
- Materials: 7075-T6 Aluminum, 316L Stainless, Titanium 6Al-4V
- Geometry: Isogrid Relief Pattern for 40% Weight Reduction
